Heatcraft IntelliGen Troubleshooting & Error Codes

Guide
Share
How to Take Apart and Clean a Blendtec Commercial Blender

Heatcraft produces high-tech solutions and parts for refrigeration. When it comes to installing, troubleshooting or maintaining them, you can trust our guides to help. If you notice an error code appearing or you’re having an issue with the unit, use our Heatcraft IntelliGen troubleshooting tips to find the solution you need.

Troubleshooting the Displays

If there’s an issue with the displays, then you’ll want to pay attention to these Heatcraft Intelligen troubleshooting tips to get the system running again.

Light Bar on the iRC UI

  • Green Light – This means the unit is running smoothly.
  • Yellow Light – A solid yellow light means there’s  an error on one or more of the evaporators.
  • Flashing Yellow Light – This indicates which unit has the error.
  • Red Light – A red light means an alarm is going off on the evaporators of the unit.

OLED Display

If there is an error or an alarm, the code will appear on the OLED display. See the list below to find the meaning of these error codes and alarms.

Heatcraft IntelliGen Error Codes & Meanings

Error Code

Meaning


ER01


Box Temp


ER02


Coil Temp


ER03


EV Suc Temp


ER04


EV Suc Press


ER11


Control Circuit (only if CU wired)


ER13


Spare I/O


ER14


Power Supply Low


ER15


Power Supply High


ER16


Low Superheat


ER18


Aux Probe Temp


ER19


Replace Battery


ER20


Log Disrupted


ER22


UI Failure


ER23


Board Comm


ER24


Aux Temp Override


ER25


System Cxn Lost


ER26


EV Cxn Lost


ER27


High Humidity


ER28


Low Humidity


ER29


Humidity Sensor


ER31


LL Conn Lost - (last three digits of the IP address)

Heatcraft IntelliGen Alarms & Meanings

Alarms

Meaning


AL01


High Box Temp


AL02


Low Box Temp


AL03


System Startup (only if CU wired)


AL04


Input Fault (ER01/ER03/ER04)


AL06


Door Open


AL10


LL High Box Temp


AL11


LL Low Box Temp

Test Mode

Test Mode can be helpful with Heatcraft IntelliGen troubleshooting, but must be initiated in Service Mode. Once turned on, the system will automatically cycle through the outputs on the iRC board to energize each one separately for 10 seconds. This process will repeat 3 times and then return to Service Mode.

If you need any more troubleshooting tips or want to know how to use a Heatcraft IntelliGen unit, check out our Heatcraft manuals and diagrams.

Please contact a local authorized service agent who can help with these specific units and all your commercial kitchen equipment needs.
