T&S Brass Wall Mount Faucet Installation Instructions
Get hands washed and sanitized when you have the right faucet installed. We will help you go over T&S Brass wall mount faucet installation instructions, helping you attach washers and faucet assemblies in a few short steps. That way you can get water running again and get things cleaned.
The following guide works for the T&S Brass B-0230 and S-0230 faucet models.
Supplies
Faucet Installation
- Step 1. Insert lock washer (optional) - Insert the lock washer into the faucet body opening if you’re converting to a rigid nozzle.
- Step 2. Insert the nozzle assembly/washers into the faucet body, then rotate to the front of the sink.
- Step 3. Tighten the nut firmly with a wrench.
- Step 4. Shut off the water supply and drain lines.
- Step 5. Drill 2 holes in the wall, making sure that they have a 1 in. diameter with 8 in. between centers.
- Step 6. Apply some teflon tape or pipe joint compound to the water supply lines.
- Step 7. Connect the faucet body to the water supply lines by attaching the assembly onto the nipple and tighten against the wall. Make sure the washer is in place.
- Step 8. Turn on the water supply and check for any leaks.
How to Install the ULTRARINSE Sprayer Attachment
- Step 1. Unscrew the nozzle from the T&S Brass faucet.
- Step 2. Insert the ULTRARINSE sprayer into the faucet and tighten the nut.
- Step 3. To ensure a strong connection, keep the lock washer in the ULTRARINSE swivel outlet.
- Step 4. Insert the removed nozzle into the top of the ULTRARINSE and tighten the nut.
For more installation instructions or troubleshooting tips, browse our T&S Brass manuals and diagrams.
