Concordia Coffee Systems Cleaning

Video
Share

Subscribe on YouTube

Keeping a clean coffee machine will prevent build-up from damaging the system. Below we have listed the daily and monthly cleaning procedures that should be completed for both the Xpress and Integra Concordia Coffee Systems. Make sure you reference the cleaning cards attached to the machine for extra detailed cleaning procedures.

Supplies

Daily Cleaning

A Concordia coffee maker needs to be cleaned after 150 drinks or every 24 hours. Otherwise the unit will stop dispensing.

Milk System Cleaning

  • Step 1. For XT models, flip the service switch to CLEAN. For Integra models, switch it to SERVICE.
  • Step 2. Close the doors and select CLEANING SERVICE on the display.
  • Step 3. Choose DAILY CLEANING and press CONTINUE on the display.
  • Step 4. Remove all milk containers and press CONTINUE on the display.
    • Note: Place milk into a cooler or refrigerator during cleaning.
  • Step 5. Remove the grounds bin and dispose of the contents.
  • Step 6. Rinse the grounds bin at a sink.
    • Note: Let the bin air dry before reinstalling.
  • Step 7. Reinstall the bin and press CONTINUE twice on the display.
  • Step 8. Place cleaner cup #1 under the dispenser and press CONTINUE.
    • Note: Wait for dispensing to finish before proceeding.
  • Step 9. Set cleaner cup #1 aside once dispensing is done and place cleaner cup #2 under the dispenser.
    • Note: Don’t pour out the contents from cup #1.
  • Step 10. Press CONTINUE and wait for the unit to finish dispensing.
  • Step 11. Set cleaner cup #2 aside once dispensing is complete and place the hot water cup under the dispenser.
    • Note: Don’t pour out the contents from cup #2.
  • Step 12. Press CONTINUE and wait for the unit to finish dispensing.
  • Step 13. Mix cleaner pack #1 with cup #1.
  • Step 14. Place the milk tubes into the solution and press CONTINUE.
  • Step 15. Place the safety cleaning tube under the nozzle and press CONTINUE.
  • Step 16. Wait for the unit to finish the first round of cleaning.
  • Step 17. Mix cleaner pack #2 in cup #2 and place the milk tubes into the solution.
  • Step 18. Press continue and wait for the unit to finish cleaning.
  • Step 19. Remove the milk tubes from cleaner cup #2 and place them into the hot water cup. Then press CONTINUE on the display.
  • Step 20. When the rinsing cycle finishes, remove the milk tubes from the hot water cup and clean the refrigerator interior and bottom trays with a damp cloth.
  • Step 21. Wipe down the milk tubes with a cloth dampened in sanitizing solution.
  • Step 22. Reload the milk containers into the unit and press CONTINUE on the display.

Brew System & Exterior Cleaning

  • Step 1. Put a cleaning tablet into the brew chamber and securely close the unit door.
  • Step 2. Press CONTINUE on the display and wait for the unit to finish cleaning.
  • Step 3. Remove the safety cleaning tube and clean the dispense nozzles with a damp cloth.
  • Step 4. Remove and clean both sides of the drain grate with a damp cloth.
  • Step 5. Clean the plastic drain tray and dispenser area with a damp cloth.
  • Step 6. Reinstall the drain grate.
  • Step 7. Use a warm cloth to wipe down the unit exterior and underneath it.
  • Step 8. (Integra Models) - Clean the product outlet with a mixture of mild soap and water. Use a soft cloth and rinse thoroughly.
  • Step 9. Flip the service switch to VEND and press FINISH on the display.

Monthly Cleaning

Monthly cleaning of Concordia machines is important to prevent damage from build-up.

  • Checking the air filter - Check the air filter for dust and grime build-up. If the filter is dirty or damaged, it needs to be cleaned or replaced.
  • Clean the bean hopper - Place a hopper stopper into the bean hopper and remove the bean hopper. Clean the inside of both bean hopper compartments with warm soapy water, and rinse thoroughly. Dry the inside of the hopper and refill it. Once back in place, remove the stopper.
  • Replace the Upper Piston O-Ring (Integra Models) - Be sure to replace the o-ring every 5,000 drinks. Start by opening the doors and brushing the upper piston and o-ring area. Press both sides of the o-ring and pull it towards you. Press down on the exposed edge and roll the o-ring down and off of the upper piston. Once the o-ring is fully removed, clean the piston and o-ring groove. Position a new o-ring around the bottom of the piston and roll it up and into place in the groove. Make sure it is snugly in place. Once the o-ring is replaced, reset the o-ring counter.

Please contact a local authorized service agent who can help with these specific units and all your commercial kitchen equipment needs.
