WMF Coffee Machine Cleaning Instructions

Guide
Share
Picture - WMF Coffee Machine Cleaning Instructions

WMF coffee machines’ intuitive touchscreen, automated functions and small footprints make these high-performance units valuable additions to any foodservice setting. Since proper care of essential equipment is important, these WMF coffee machine cleaning instructions will help you keep your unit safe and sanitary while also maximizing performance.

These instructions are applicable to the 1500S model.

Supplies

Follow the cleaning procedures and time intervals as outlined below for improved performance and hygiene. If your machine isn’t used for a few days in a row, be sure to complete all of the cleaning tasks outlined below prior to resuming use.

Daily System Cleaning

Know that maintaining the mixer, milk system and foamer is part of the programmed system cleaning process; however, if you wish to rinse one of these parts individually, you can do so by choosing the appropriate program under the Care Menu.

  • Step 1. Access the Care Menu - Open the Care Menu by pressing the “Care” button in the upper left-hand corner of the touchscreen.
  • Step 2. Select “Cleaning program” - Press “Cleaning program” in order to advance to the next screen.
  • Step 3. Choose “System cleaning” - Select “System cleaning” to begin the maintenance procedure.
  • Step 4. Confirm On/Off after cleaning - Decide whether you want the unit to stay on or switch off after cleaning by pressing either “On” or “Off” at the bottom of the touchscreen.
  • Step 5. Empty the grounds container - Lift up the dispense head, pull out the grounds container, throw out the grounds and then return the container to the unit.
  • Step 6. Put the milk pipe into the plug-and-clean socket - Open the milk chiller and pull out the milk pipe. Then, pull down the left flap on the unit, insert the milk pipe into the socket and turn it clockwise to lock it into place.
  • Step 7. Add a cleaning tablet - Insert a special cleaning tablet into the slot at the top of the machine.
  • Step 8. Begin the cleaning program - Select “OK” on the touchscreen after adding the special cleaning tablet; the system cleaning cycle will then begin automatically.

Daily Manual Cleaning

Avoid using abrasive pads or harsh chemicals as these may damage the machine’s internal components and exterior surfaces.

Operating Panel

  • Step 1. Select the Care Menu - Choose the “Care” option in the upper left-hand corner of the screen.
  • Step 2. Lock the touchscreen - Touch the “CleanLock” icon to lock the screen for 15 seconds.
  • Step 3. Clean the display - Use the 15-second period of time to wipe the display with warm, soapy water, then rinse it with a damp cloth.
  • Step 4. Dry the touchscreen - Use a cloth to wipe up any remaining moisture.

Grounds Container

  • Step 1. Remove the container - Take out the grounds container by lifting up the dispense head, grabbing the container and then pulling it out.
  • Step 2. Empty the bin - Shake out the container over a garbage can.
  • Step 3. Clean the container - Wash the bin with warm, soapy water before rinsing it out with fresh, clean water.
  • Step 4. Dry the bin - Wipe up any excess water with a soft cloth.
  • Step 5. Reinstall the container - Return the grounds container to the unit.

Drip Tray & Housing

  • Step 1. Pull out the drip tray - Remove the drip tray by lifting it up and then out of the unit.
  • Step 2. Clean the drip tray - Wash the drip tray with warm, soapy water, then rinse away any remaining suds or residues with clean water.
  • Step 3. Dry the tray - Use a soft towel to soak up any excess moisture.
  • Step 4. Reinstall the tray - Return the drip tray to the unit.
  • Step 5. Clean the housing - Wipe down the unit exterior with warm water, mild detergent and a soft cloth. When cleaning metal cover parts, remember to use WMF Purargan® cleaner.

Weekly Procedures

Feel free to clean the mixer and foamer more often than once a week if needed.

Water Tank

  • Step 1. Remove the water tank - Pull out the water tank on the right-hand side of the machine.
  • Step 2. Wash out the tank - Rinse the tank with warm, clean water.
  • Step 3. Dry the tank - Use a soft cloth to wipe up any remaining water.
  • Step 4. Return the water tank to the unit - Reinstall the tank in the machine.

Foamer & Milk Pipe (If Using With a Milk Chiller)

  • Step 1. Uninstall the foamer - Lower the dispenser down and pull out the foamer. Then, remove the milk and hot chocolate pipes so that the foamer is no longer attached to the machine.
  • Step 2. Disassemble the foamer - Pull the side tabs apart and separate the foamer into two parts before peeling off the green top.
  • Step 3. Remove the milk pipe - Open the milk chiller, pull out the pipe and take off the plastic pipe end. Next, open the left-hand flap on the front of the unit and feed the milk pipe into the milk chiller so that you can pull the pipe out of the machine completely.
  • Step 4. Soak the foamer and milk pipe - Soak the foamer and milk pipe in WMF Special Cleaner solution for 5 hours. Be sure to rinse and dry these two components before returning them to the unit.
  • Step 5. Clean the foamer - Brush the foamer, including the holes, to remove unwanted residues.
  • Step 6. Return the foamer and milk pipe to the machine - Reverse the previous instructions in order to reinstall the foamer and milk pipe.

Mixer

  • Step 1. Remove the mixer - Lift the screen, release the foamer, pull out the milk pipe and then take out the mixer.
  • Step 2. Disassemble the mixer - Take apart the mixer by pulling off the top and milk pipe.
  • Step 3. Brush the mixer - Use the brushes that came with your unit to clean the mixer parts, including the small holes.
  • Step 4. Reinstall the mixer - Return the mixer to the machine by reversing the previous instructions.

Monthly Maintenance

Be sure to assess the cleanliness of the bean and powder hoppers, and clean them more frequently if necessary. Also, since long hair can get caught in the grinder head, always remember to wear a hairnet when cleaning the bean hoppers.

Pre-Cleaning Procedure

  • Step 1. Turn off the machine - Use the “On/Off” button to power down the machine.
  • Step 2. Disconnect the unit from power - Minimize the risk of electric shock by unplugging the unit’s power cord from the outlet before continuing.
  • Step 3. Empty the hoppers - Find a trash can and dispose of the contents from both the bean and powder hoppers.

Brewing Unit

  • Step 1. Access the assembly - Push up the dispense head, remove the drip tray and take out the grounds container; this will make the brew unit accessible.
  • Step 2. Pull out the brewing unit - Place your thumb on the circle on the brew assembly, then use your index finger to pull it out of the machine.
  • Step 3. Open up the assembly - Flip the insertion unit upwards in order to open up the brewing assembly for cleaning.
  • Step 4. Clean the brewing unit - Wash the brewer in warm, soapy water and then rinse in clean water.
  • Step 5. Dry the assembly - Wipe away leftover moisture with a soft cloth.
  • Step 6. Reinstall the brewing assembly - Return the brewer to the machine by following the previous directions in reverse.

Bean Hopper

  • Step 1. Uninstall the bean hoppers - Turn the lock on the bean hoppers counterclockwise to release them before lifting them off the unit.
  • Step 2. Empty out the hoppers - Open the containers over a garbage can and discard the contents.
  • Step 3. Wash the bean hoppers - Clean the bean hoppers with warm water and mild detergent before rinsing away any remaining suds or residues with clean water.
  • Step 4. Dry the containers - Use a clean cloth to wipe away any excess moisture in the bins.
  • Step 5. Refill the hoppers - Add coffee beans to the containers as desired.
  • Step 6. Reinstall the bean hoppers - Return the bean hoppers to the unit by reversing the previous instructions.

Clean Powder Hopper

  • Step 1. Pull out the powder hopper - Turn the lock on the powder hopper counterclockwise to open it, then tip it backward and pull it up and out of the unit.
  • Step 2. Shake out the bin - Hold the powder hopper over a garbage can and empty out the contents.
  • Step 3. Pull out the auger - Unscrew the union nuts and remove the dosing auger.
  • Step 4. Clean the hopper and components - Use a damp cloth to wipe out the hopper, then clean the auger components, too.
  • Step 5. Dry the components - Soak up any remaining moisture on the powder hopper and other components with a soft cloth.
  • Step 6. Reassemble the hopper - Secure the auger on the hopper by tightening the union nuts.
  • Step 7. Return the powder hopper to the unit - Reinstall the powder hopper by reserving the instructions.

If you found this information helpful, take a look at the large library of WMF parts and diagrams on our site.

Please contact a local authorized service agent who can help with these specific units and all your commercial kitchen equipment needs.
