Multiplex Blend-In-Cup Troubleshooting
Taking customers’ favorite drinks off the menu because of technical or mechanical difficulties can compromise your brand reputation and, ultimately, your bottom line. That’s where Multiplex Blend-in-cup troubleshooting comes in. Sometimes, just knowing there’s something you can do can go a long way in easing tensions and tempers when things don’t go according to plan. So whether your Multiplex Blend-in-cup machine is not turning on, dispensing, filling or generally not working, Parts Town can help set you on the path to minimizing downtime and strengthening customer relationships.
Not Turning On
Cause | Solution |
Blown fuse | Replace fuse |
Tripped circuit breaker | Reset circuit breaker |
Unplugged power cord | Plug in power cord |
Main power switch is off | Turn main power switch on |
Temperature set too high | Lower temperature |
Faulty power outlet | Please contact an authorized service technician |
Power outage | Please contact your local electric company |
Display Screen Not Working
Cause | Solution |
Control board is locked | Program recipe in Menuconnect. Then, transfer it to the main system via USB drive |
No installed recipe | Unplug the main power cord and plug back in to reset. |
Not Dispensing
If your smoothies or frappes resemble watered-down versions of their former glory, try these Multiplex blend-in-cup troubleshooting pointers:
- CO2 pressure is too low - If your Multiplex blend-in-cup is not dispensing properly, it might be a matter of a low CO2 canister. You can resolve the problem by replacing the canister. If it’s still not working, double-check that the lines are open and the regulator is set at 35 psi. The CO2 shutoff valve should be in the cabinet below the sink and the other next to the beverage rack.
- Product is empty – Select the inventory icon on the main menu and check the status of the product lines. Here, it will tell you if any need to be replaced.
- Product bag is pinched – It could be that the product bag was pinched in a way that no product can flow into the connector. Readjust the bag so that there are no pinched or buckled areas.
- Product is frozen – It might be that not enough time was allowed for the product bag to dethaw after taking it out of the freezer. Wait 48 hours before loading the new product into the cabinet.
- No water supply or low water pressure – Ensure the water supply is turned on and the plain or chilled water supply regulator is set between 65-90 psi.
- Product is not installed or installed incorrectly - It might be that there are no product bags installed or that they were installed incorrectly. Check each bag to ensure the connector (without the cap) is correctly positioned in the tray and coupled with the product inlet tubes.
- Product line blocked - Sometimes, if you can’t coax your beverage out of the dispenser, it’s because there’s a blockage in the product line. Check the line and follow the steps as outlined below if you notice a blockage.
- Ice not dispensing - If the ice is not dispensing, follow the procedures as outlined in the section below.
How to Clear a Blocked Line
A blocked product line can cause dispensing problems in your Multiplex blend-in-cup. Follow the steps below to clear the blockage and get to churning out your favorite slushies, shakes, smoothies and frappes.
- Step 1. Add warm water to a squirt bottle – First, you’ll want to grab a squirt bottle and fill it with warm water.
- Step 2. Remove the product bin – Next, remove the product bin from the cabinet so you can attach the squirt bottle to the product inlet tube with vinyl tubing.
- Step 3. Press the inventory icon and the product line – On the main menu, hit the inventory icon. This will take you to a screen showing product levels in all your lines. Select the one with the blockage.
- Step 4. Press the green arrow two times – Without following the product replacement instructions, hit the green arrow two times in a row.
- Step 5. Choose Prime Flavor – From there, select the middle icon labeled “Prime Flavor” and place a cup under the dispenser to catch the water you’ll push through the line with the squirt bottle.
- Step 6. Choose Hold to Prime – Press the Hold to Prime icon while squeezing the squirt bottle. Product should enter the fill cup.
- Step 7. Repeat step 6 – Repeat step 6 until the blockage clears.
- Step 8. Return the product bin – Detach the squirt bottle from the vinyl tubing and product inlet tube and return the product bin to the cabinet.
- Step 9. Choose Hold to Prime – Afterward, check that the product bin was reattached correctly and the blockage is cleared by pressing the Hold to Prime button. Product should dispense into the cup.
- Step 10. Press the green arrow – Once you’ve verified your Multiplex BIC machine is dispensing properly again, press the green arrow to exit.
Ice Not Dispensing
Cause | Solution |
Misaligned ice bin cover | Position ice bin cover so the mark on the cover aligns with the ice bin |
Not enough ice in bin | Add more ice |
Foreign objects blocking the ice rotor | Remove foreign objects |
Tripped circuit breaker | Reset circuit breaker in the back, left corner |
Ice stuck in chute | Dislodge ice from chute with a straw |
Warning: Never scoop or dig through ice with your hands, as there is a very sharp ice shaving blade hiding beneath. Always use an ice scoop to avoid injury.
Not Blending
Cause | Solution |
Open blender door | Close blender door |
Open blender door switch | Please contact an authorized service technician |
Misaligned drain grid | Align drain grid properly |
Door is off its track | Insert door in its tracks |
Not Filling Cup Properly
Cause | Solution |
Product not installed correctly | Check each bag to make sure the connector (without the cap) is correctly positioned in the tray and coupled with the product inlet tubes |
Product is empty | Replace product bag |
Product bag is pinched | Readjust product bag |
Ice dispenser out of calibration | Calibrate ice dispenser |
Empty CO2 canister | Replace CO2 canister |
CO2 pressure too low | Check the lines are open and the regulator is set at 35 psi |
Not enough ice in bin | Add ice to bin |
Cup Overflowing
Cause | Solution |
Product is too warm | Allow time for product to cool |
Product bag is compressed | Readjust product bag or remove any foreign objects |
Water pressure is too high | Lower water pressure |
Water dispenser out of calibration | Calibrate water dispenser |
Product was reassigned to alternative spot | Perform dispenser calibration |
Ice dispenser out of calibration | Calibrate ice dispenser |
Flavor dispenser is out of calibration | Calibrate flavor dispenser |
CO2 pressure too high | Ensure CO2 pressure is 35 psi |
Product lines are too hot after cleaning procedure | Wait 30 minutes for product lines to cool down. If problem persists, recalibrate |
Compressor Runs Continuously
Cause | Solution |
Too much warm product was loaded in the cabinet | Wait for product to cool down before loading the unit |
Open door | Close door |
Faulty door gasket | Replace door gasket |
Dirty condenser coil | Clean condenser coil |
There’s ice on the evaporator coil |
|
High Product Temperature Error
Cause | Solution |
Open door | Close door |
Open whipped cream door | Close whipped cream door |
Faulty door gasket | Replace door gasket |
Too much warm product was loaded in the cabinet | Wait for product to cool down before loading the unit |
Dirty condenser filter | Clean condenser filter |
Not Rinsing Properly
Cause | Solution |
Water supply line is not connected | Connect water supply line |
Open door | Close door |
Misaligned drain grid | Align drain grid |
Door is off its tracks | Insert door in its tracks |
So you have your Multiplex Blend-in-cup troubleshooting squared away, but the best way to ensure no future trouble is abiding by a strict preventative maintenance schedule. Check out our Multiplex cleaning guide to ensure only the best-tasting drinks get dispensed into your customer’s awaiting cups.
